stepper driver MC556E 50V 5.6A (2 phase)

Specifications:

Voltage input range: DC20V～50V
Maximum peak current: 5.6A
Subdivision range: 400～25600ppr
Pulse form: pulse + direction or CW/CCW Mode (5VDC to 24VDC)
Impulse response frequency: 0～200KHz
Motor parameter auto-tuning function
With protection functions such as overvoltage,
overcurrent, tracking error out of tolerance, etc.

Manual:

MC556Manual.PDF
