Input Voltage 24-70VAC or
30-100VDC
Output Current 6A 20KHz PWM
Pulse Frequency max 200K
Communication rate 57.6Kbps
Protection
-Over current peak value12A±10%
-Over voltage value130V
-The over position error range can be set through the HISU
Overall Dimensions（mm） 150×97.5×53
Weight Approximate 580g
Coolingmethod: Natural cooling or forced air cooling
