Parameter Description | ||
Axis output control: | Drive Current | Isolated open collector output; 5V,20mA |
Drive | Pulse + direction output | |
Output frequency | 400KHZ | |
axes | MK4: 4-axis | |
Isolation Voltage | 3.5KV | |
Spindle inverter output: 3 types of output modes | Analog voltage output | 0-10V |
PWM output | 5V,1KHZ.Duty; 0-100% | |
Pulse + direction output | 5V,15HZ to 4KHZ | |
8 IO output | Drive Current | Isolation;50mA,25V |
Isolation Voltage | 3.5KV | |
16 IO input | Input Current | Isolated inputs,5mA,maximum voltage 25V |
Isolation Voltage | 3.5KV | |
USB interface | Complies with USB 2.0 standard | |
